Mersen AMP-TRAP® 2000 SmartSpot® AJT8 Current Limiting Low Voltage North American Time Delay Power Fuse, 8 A, 600 VAC, 200 kA Interrupt, J Class, Cylindrical Body

Selected Mersen AMP-TRAP® 2000 SmartSpot® AJT8 Current Limiting Low Voltage North American Time Delay Power Fuse, 8 A, 600 VAC, 200 kA Interrupt, J Class, Cylindrical Body
Mersen AMP-TRAP® 2000 SmartSpot® AJT8 Current Limiting Low Voltage North American Time Delay Power Fuse, 8 A, 600 VAC, 200 kA Interrupt, J Class, Cylindrical Body

Documents

Short Description

Amp-Trap 2000 time-delay AJT fuses provide IEC Type "2" (No Damage) protection to main, feeder, and branch circuits, for all types of loads - yet, they require only half the mounting space needed for 600V UL Class RK fuses. Time-delay characteristics handle motor inrush currents without nuisance trips. Its current-limiting ability and wide range of ratings provide excellent over current protection for all your applications. An optional mechanical blown fuse indicator and Micro switch is available on blade-type (70 to 600A) fuses for visual and/or remote blown fuse indication.

Features

  • Solid state SmartSpot visual blown fuse indicator
  • Time-delay for motor starting and transformer inrush
  • Extremely current-limiting for low peak let-thru current
  • Most current-limiting UL class fuse
  • Small footprint requires less mounting space and allows smaller, more economical fuse blocks
  • Easy 2-to-1 selectivity for prevention of nuisance shutdowns
  • High-visibility orange label gives instant recognition
  • Metal embossed date and catalog number for traceability and lasting identification
  • Fiberglas body provides dimensional stability in harsh industrial settings
  • High grade silica filler ensures fast arc quenching
  • Arc flash mitigating
  • North American power fuses

Specification

Interrupt Rating
200/100 kA
Material
GMG
Mounting Type
Holder
Minimum Order Qty
1
Order Interval
1
Body Style
Cylindrical
Class
J
Element
Dual
Series
AJT
Terminal Type
Ferrule
Type
Current Limiting
Voltage Rating
600 VAC
Application
Motor Circuits, Mains, Feeders, Branch Circuits, Lighting, Heaters, Transformers, Control Panels, Circuit Breaker Back-up, Bus Duct and Load Centers
Standard & Approvals
UL 248-8, UL File No. E2137, CSA C22.2 No. 248.8, IEC 269-2-1, RoHS Compliant
Amperage Rating
8 A
Catalog ID
GOUAJT8
Body Size
13/16 in Dia x 2-1/4 in L
