Mersen Amp-Trap® ATMR2 Current Limiting Low Voltage Fast Acting Fuse, 2 A, 600 VAC/VDC, 200/100 kA, Class CC, Cylindrical Body

Selected Mersen Amp-Trap® ATMR2 Current Limiting Low Voltage Fast Acting Fuse, 2 A, 600 VAC/VDC, 200/100 kA, Class CC, Cylindrical Body
Mersen Amp-Trap® ATMR2 Current Limiting Low Voltage Fast Acting Fuse, 2 A, 600 VAC/VDC, 200/100 kA, Class CC, Cylindrical Body

Documents

Short Description

Amp-Trap ATMR fuses, in the Class CC family, are the smallest dimension 600V fuses suitable for branch circuit protection. The ATMR is a popular choice for economical protection of control circuits and control circuit transformers where available short circuit currents exceed 10,000 amperes. ATMR's rejection dimensions prevent substitution by lesser rated fuses. These fast acting fuses give current limiting protection to general circuits.

Features

  • Rejection style design prevents replacement errors when used with recommended fuse blocks
  • Fiberglass body provides dimensional stability in harsh industrial environments
  • Versatile design for individual component and branch circuit protection
  • Tin-plated copper contact material
  • North American power fuses

Specification

Interrupt Rating
200/100 kA
Material
GMG
Mounting Type
Holder
Minimum Order Qty
1
Order Interval
1
Body Size
13/32 in Dia x 1-1/2 in L
Body Style
Cylindrical
Catalog ID
GOUATMR2
Class
CC
Element
Single
Series
ATMR
Terminal Type
Ferrule
Voltage Rating
600 VAC/VDC
Application
Control Circuits, Lighting, General Loads and Branch Circuit Protection
Standard & Approvals
UL 248-4, CSA C22.2, No. 248.4
Amperage Rating
2 A
