Mersen UltraSafe™ USCC3 Fuse Holder, 600 VAC/VDC, 30 A, 14 to 6 AWG Wire, 3 Poles

Selected USCC3Mersen UltraSafe™ USCC2 Fuse Holder, 600 VAC/VDC, 30 A, 14 to 6 AWG Wire, 2 Poles
USCC3Mersen UltraSafe™ USCC2 Fuse Holder, 600 VAC/VDC, 30 A, 14 to 6 AWG Wire, 2 Poles

Documents

Short Description

Mersen UltraSafe™ Modular Fuseholders introduce a new level of safety for Class CC (USCC) AC and DC-rated fuses up to 30 amperes. UltraSafe™ holders qualify as "Finger-safe" under IEC and DIN standards to an IP20 grade of protection, including fuse changing (with the flick of a finger). UltraSafe™ holders are available in 1, 2, 3 or 4 poles, with or without visual blown fuse indicators in each pole. Multi-pole units can also be field assembled by ordering pin-tie handles.

Features

  • UltraSafe™ holders save up to 15 percent mounting space and any combination can be snapped onto 35mm DIN-rail for extra savings in panel building time
  • UltraSafe™ holders with Class CC fuses chosen for Type "2" No Damage protection give one of the safest protection packages in the industry
  • UltraSafe™ body material is tough and durable polyamide, with exceptional insulating properties
  • IP20 Finger-Safe (touch safe)
  • Optional visual blown fuse Indicator lights
  • Compact footprint
  • Quick, tool free, easy fuse change-outs
  • Phillips/slot head terminal screws
  • 14 - 6 AWG (single conductor), 14 - 10 AWG (dual conductor) wire size

Specification

Fuse Holder Code
D/W
Material
Polyamide
Mounting Type
DIN Rail
Number Of Poles
3
Minimum Order Qty
1
Order Interval
1
Amperage Rating
30 A
Catalog ID
GOUUSCC3
Class
CC
Connection Type
Pressure Plate
Dimensions
3.07 in L x 2.07 in W x 2.32 in H
Series
UltraSafe
Suitable For Use With
ATDR, ATMR, ATQR Series Fuses
Temperature Rating
-40 to 85 deg C
Voltage Rating
600 VAC/VDC
Wire Size
14 to 6 AWG
Application
All Circuits (including Branch-circuits) Upto 600 Volts (AC or DC) For Motors, Control Circuits and Transformers
Standard & Approvals
UL 4248-4, File No. E52283, CSA C22.2, Class 6225, File No. 32169, RoHS Compliant
