Finder® 46.52.9.024.0074 46 Series Miniature Power Relay, 8 A, 2CO/DPDT Contact, 24 VDC V Coil
Finder® 46.52.9.024.0074 46 Series Miniature Power Relay, 8 A, 2CO/DPDT Contact, 24 VDC V Coil
SKU: F-R46.52.9.024.0074
Manufacturer Part Number: 46.52.9.024.0074
UPC: 465290240074
Documents
Features
- AgNi standard contact material
- DC coils, 500 mW or AC coils, 1.2 VA
- 8 mm, 6 kV (1.2/50 us) isolation, coil-contacts
- Cadmium free contact material
- Coil indication and EMC suppression modules
- 15 A maximum peak current
- 0.37 kW single-phase motor rating (230 VAC )
- 300 mW minimum switching load
- 10 ms operate time
- 3 ms release time
- 1000 VAC dielectric strength between open contacts
- 5 mm contact pin pitch
- Lockable test button, double LED (DC non-polarized) and mechanical indicator
Specification
| Number Of Poles | 2 |
|---|---|
| Temperature Rating | -40 to 70 deg C |
| Type | Miniature |
| Coil Voltage | 24 VDC |
| Contact Form | 2 CO (DPDT) |
| Amperage Rating | 8 A |
| Dimensions | 32.8 in H x 29 in W x 12.4 in D |
| Standard & Approvals | cULus Listed, CSA Certified, PCT Approval, VDE Certificate, RINA Certification, CE Listed, Lloyd's Register |
| Application | Air Conditioners, Automatic Car-Washes, Bottling Plant and Automation for Blinds, Grilles and Shutter |
| Terminal Type | Spade/Blade Solder |
| Series | 46 |
