***CLOSEOUT*** GE 9T51B0504 Type QB Dry Type Encapsulated General Purpose Transformer, 240x480 VAC Primary, 120/240 VAC Secondary
***CLOSEOUT*** GE 9T51B0504 Type QB Dry Type Encapsulated General Purpose Transformer, 240x480 VAC Primary, 120/240 VAC Secondary
SKU: G-E9T51B0504
Manufacturer Part Number: 9T51B0504
UPC: 783173011201
Documents
Features
- Feature an encapsulated core and coil in a NEMA 3R non-ventilated weatherproof enclosure
- Knockouts provided on back and bottom
- High grade silicon steel core
- Mounting holes on side for easy access
- Copper coil
- Indoor/outdoor use
- No taps
- 55 deg C temperature rise
- 105 deg C temperature class
- K1 K factor
Specification
| Frequency Rating | 50 Hz |
|---|---|
| Insulation | Class A |
| Phase | 1 |
| Power Rating | 0.10 kVA |
| Primary Voltage | 240x480 VAC |
| Secondary Voltage | 120/240 VAC |
| Temperature Rating | 40 deg C |
| Type | Type QB Dry Type Encapsulated |
| Standard & Approvals | UL Listed |
| Dimensions | 5.12 in W x 6.38 in H |
| Circuit Type | 6200 Frame |
| Closeout | YES |
| Enclosure Type | NEMA 3R |
