GE Current UltraMax™ Multi-Volt ProLine® GE Current232MAXPH/ULTRA Professional High Efficiency Electronic Ballast, T8 Fluorescent Lamp, 32 W Lamp, 120 to 277 VAC, Instant, 1.18 Ballast Factor
GE Current UltraMax™ Multi-Volt ProLine® GE Current232MAXPH/ULTRA Professional High Efficiency Electronic Ballast, T8 Fluorescent Lamp, 32 W Lamp, 120 to 277 VAC, Instant, 1.18 Ballast Factor
SKU: GELGE232MAX-H
Manufacturer Part Number: GE232MAXPH/ULTRA
UPC: 043168731904
Documents
Short Description
Features
- High ballast factor
- 74 W at 120 V, 73 W at 277 V
- 0.62 A at 120 V, 0.27 A at 277 V amperage rating
- >=99% at 120 V, 98% at 277 V power factor
Specification
| Frequency Rating | 60 Hz |
|---|---|
| Lamp Type | T8 |
| Lamp Wattage | 32 W |
| Minimum Starting Temperature | -20 deg F |
| Number of Lamps | 2 |
| Power Factor | >=0.98/0.99 |
| Series | Professional |
| Start Type | Instant |
| Temperature Range | -20 to 131 deg F |
| Total Harmonic Distortion | <=10% |
| Type | High Efficiency |
| Voltage Rating | 120 to 277 VAC |
| Wattage | 73/74 W |
| Amperage Rating | 0.62/0.27 A |
| Dimensions | 9.5 in L x 1.3 in W x 1 in H |
| Ballast Factor | 1.18 |
| Enclosure Type | NEMA 1 |
