GE Q-Line TEY215 Type TEY Thermal Magnetic Lighting Panel Circuit Breaker, 277/480 VAC, 15 A, 14 kA Interrupt, 2 Poles

Selected TEY260GE Q-Line TEY215 Type TEY Thermal Magnetic Lighting Panel Circuit Breaker, 277/480 VAC, 15 A, 14 kA Interrupt, 2 Poles
TEY260GE Q-Line TEY215 Type TEY Thermal Magnetic Lighting Panel Circuit Breaker, 277/480 VAC, 15 A, 14 kA Interrupt, 2 Poles

Documents

Short Description

The TEY is a one-inch wide per pole, compact, "bolt-on" circuit breaker for use on grounded 480Y/277 Vac systems. The bolt-on mounting base accessory makes the TEY suitable for varied applications as a lug-lug breaker. All TEY circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. TEY breakers are available in 1, 2, and 3 pole versions and can be ordered with auxiliary contact and shunt trip accessories.

Features

  • For use with GE AE lighting panels
  • The TEY is a one-inch wide per pole, compact, "bolt-on" circuit breaker for use on grounded 480Y/277 VAC systems
  • The bolt-on mounting base accessory makes the TEY suitable for varied applications as a lug-lug
  • Standard continuous current rated
  • With non-interchangeable trip unit

Specification

Interrupt Rating
14 kA
Mounting Type
Bolt-On
Number Of Poles
2
Minimum Order Qty
1
Order Interval
1
Amperage Rating
15 A
Catalog ID
G-ETEY215
Connection Type
Screw Clamp
Dimensions
5.25 in H x 2 in W x 3.06 in D
Phase
1
Temperature Rating
40 deg C
Trip Type
Long Time and Instantaneous
Type
Type TEY Thermal Magnetic
Voltage Rating
277/480 VAC
Wire Size
4 to 1/0 AWG
Standard & Approvals
UL E11592 Listed, CSA LR57114 Certified, HACR, HID, GSA Rated
Application
For varied applications as a lug-lug breaker
