GE TEYD3125B Type TEY Compact Lighting Panel Circuit Breaker, 120/240/277/480 VAC, 250 VDC, 125 A, 25/65 kA Interrupt, 3 Poles, Thermal Magnetic Trip

Selected GE TEYD3125B
GE TEYD3125B

Documents

Short Description

The TEY is a 1 in W per pole, compact, "bolt-on" circuit breaker for use on grounded 480Y/277 VAC systems. The bolt-on mounting base accessory makes the TEY suitable for varied applications as a lug-lug breaker. all TEY circuit breakers feature quick-make quick-break mechanisms, common trip bars and easy to spot trip indication to ensure safety and reliability. TEYD breakers are available in 1, 2 and 3-pole versions, 2 and 3-pole versions can be ordered with auxiliary contact, shunt trip, under voltage release or bell alarm accessories.

Features

  • Ambient compensated
  • Multiple short circuit tiers
  • Cost effective protection
  • Mounting base for unit mount installations
  • 65 kA at 120/240 VAC, 65 kA at 240 VAC, 25 kA at 480Y/277 VAC interrupt rating

Specification

Material
Plastic
Series
TEYD
Wire Size
4 to 2/0 AWG
Voltage Rating
120/240/277/480 V AC/250 V DC
Dimensions
3 in W x 3-1/16 in D x 5-1/4 in H
Mounting Type
Bolted-On
Type
Type TEY Compact
Amperage Rating
125 A
Temperature Rating
40 deg C
Trip Type
Thermal Magnetic
Connection Type
Load Lug
Phase
3
Interrupt Rating
25/65 kA
Number Of Poles
3
Frequency Rating
50/60 Hz
Actuator Type
Pivot/Toggle Handle
Frame
TEYD
