General Electric TFN60R General Electricneral Duty Non-Fusible Pullout Air-Conditioner Disconnect, 240 VAC, 60 A, 10 hp, 2 Poles
General Electric TFN60R General Electricneral Duty Non-Fusible Pullout Air-Conditioner Disconnect, 240 VAC, 60 A, 10 hp, 2 Poles
SKU: G-ETFN60R
Manufacturer Part Number: TFN60R
UPC: 783164209860
Features
- Easy installation
- On pull out model, handle stores inside enclosure in off position
Specification
| Frequency Rating | 50/60 |
|---|---|
| Material | Steel |
| Number Of Poles | 2 |
| Phase | 1 |
| Type | General Duty Non-Fusible Pullout |
| Voltage Rating | 240 V |
| Standard & Approvals | UL 1429, cULus Listed |
| Amperage Rating | 60 A |
| Dimensions | 7.5 in H x 5.2 in W x 2.5 in D |
| Enclosure Type | NEMA 3R |
| Horsepower | 10 hp |
