General Electric Q-Line THQC1120WL Type THQC Molded Case Circuit Breaker, 120/240 VAC, 20 A, 10 kA, 1 Pole, Long Time/Instantaneous Trip
General Electric Q-Line THQC1120WL Type THQC Molded Case Circuit Breaker, 120/240 VAC, 20 A, 10 kA, 1 Pole, Long Time/Instantaneous Trip
SKU: G-ETHQC1120WL
Manufacturer Part Number: THQC1120WL
UPC: 783164012491
Documents
Features
- The QC breakers are lug-lug versions of the Q Line and are available for 35mm DIN rail mounting
- All Q Line circuit breakers feature quick make/quick break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability
- Q Line breakers are available in 1, 2, and 3 pole versions and can be ordered with auxiliary contact and shunt trip accessories
- Non-interchangeable trip
- Compact design
- Provide cost effective solutions
- Quick-connect version available
- Cu/Al wire
Specification
| Interrupt Rating | 10 |
|---|---|
| Mounting Type | Plug-In |
| Number Of Poles | 1 |
| Phase | 1 |
| Trip Type | Long Time/Instantaneous |
| Type | Type THQC |
| Voltage Rating | 120/240 V |
| Wire Size | 14 to 8 AWG/12 to 8 AWG |
| Application | For residential and commercial applications |
| Standard & Approvals | UL E11592, UL 489, Federal Specification (WC-375B), HACR Rating |
| Amperage Rating | 20 A |
| Dimensions | 3-9/32 in H x 1 in W x 2-3/8 in D |
| Connection Type | Line/Load Lug |
