General Electric Q-Line THQL32080 Type THQL Molded Case Circuit Breaker, 240 VAC, 80 A, 10 kA, 3 Poles, Long Time/Instantaneous Trip
General Electric Q-Line THQL32080 Type THQL Molded Case Circuit Breaker, 240 VAC, 80 A, 10 kA, 3 Poles, Long Time/Instantaneous Trip
SKU: G-ETHQL32080
Manufacturer Part Number: THQL32080
UPC: 783164135756
Features
- Q line circuit breakers are one-inch wide per pole, compact, thermal magnetic devices
- The QL breakers are plug-in versions of the Q Line used for connection to load centers and lighting panels
- Q Line breakers are available in 1, 2, and 3 pole versions and can be ordered with auxiliary contact and shunt trip accessories
- Can be ordered for use in HID applications
- Non-interchangeable trip
- All Q Line circuit breakers feature quick make/quick break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability
- Feeder 1 in plug-in
- Cu/Al wire
- Internal common trip
Specification
| Interrupt Rating | 10 |
|---|---|
| Mounting Type | Plug-In |
| Number Of Poles | 3 |
| Phase | 3 |
| Temperature Rating | 60 deg C/75 deg C |
| Trip Type | Long Time/Instantaneous |
| Type | Type THQL |
| Voltage Rating | 240 V |
| Wire Size | 6 to 1/0/4 to 1/0 AWG |
| Application | For residential and commercial applications |
| Standard & Approvals | UL E11592 Listed, UL 489, Federal Specification (WC-375B), HACR Rating |
| Amperage Rating | 80 A |
| Dimensions | 3-9/32 in H x 3 in W x 2-3/8 in D |
| Connection Type | Box Lug |
