nVent HOFFMAN E1PB Pushbutton Enclosure, 3-1/2 in L x 3-1/4 in W x 2-3/4 in D, NEMA 12/IP65 NEMA, Steel
nVent HOFFMAN E1PB Pushbutton Enclosure, 3-1/2 in L x 3-1/4 in W x 2-3/4 in D, NEMA 12/IP65 NEMA, Steel
SKU: HOFE1PB
Manufacturer Part Number: E1PB
UPC: 783510580100
Documents
Features
- Seams continuously welded and ground smooth
- Captivated cover screws thread into sealed wells
- Grounding nut in body of enclosure
- Bonding provision on cover
- Oil-resistant gasket
- Factory stamped 4-way pushbutton holes
- Enclosures with more than one column of pushbutton holes have internal detachable hinge
- External wall mounting brackets
- 1 number of hole
- 30.5 mm hole
- 4.5 in L x 3.47 in W overall dimension
- 16 or 14 gauge steel
- ANSI 61 gray polyester powder paint inside and out
Specification
| Length | 3.5 in |
|---|---|
| Material | Steel |
| Mounting Type | Wall |
| NEMA Rating | NEMA 12/IP65 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Catalog ID | HOFE1PB |
| Color | Gray |
| Cover Type | Hinged With Screw |
| Depth | 2-3/4 in |
| Finish | Powder Coated |
| Series | PB1 |
| Width | 3.25 in |
| Application | Designed to hold 30.5-mm or 22.5-mm pushbuttons and switches |
| Standard & Approvals | UL 508A Listed, Type 12, 13, File No. E61997, cUL Listed per CSA C22.2 No. 94, Type 12, 13, File No. E61997, RoHS Complaint |
