nVent HOFFMAN E1PBSS Pushbutton Enclosure, 3-1/2 in L x 3-1/4 in W x 2-3/4 in D, NEMA 4X/IP66 NEMA, 304 Stainless Steel
nVent HOFFMAN E1PBSS Pushbutton Enclosure, 3-1/2 in L x 3-1/4 in W x 2-3/4 in D, NEMA 4X/IP66 NEMA, 304 Stainless Steel
SKU: HOFE1PBSS
Manufacturer Part Number: E1PBSS
UPC: 783510596101
Features
- 14 gauge bodies, 16 gauge covers
- Seams continuously welded and ground smooth
- Captivated cover screws thread into sealed wells
- Bonding provision on door grounding nut on body
- 4-way pushbutton holes accept all brands of oil-tight pushbuttons, switches and pilot lights
- Enclosures with more than one column of pushbutton holes have internal detachable hinge to hold cover open during wiring, yet permit immediate removal
- Oil-resistant gasket
- 1 number of hole
- 22.5 mm hole
- 4.5 in L x 3.47 in W overall dimension
- Cover and sides of body have smooth NO 4 brushed finish
Specification
| Length | 3.5 in |
|---|---|
| Material | 304 Stainless Steel |
| Mounting Type | Wall |
| NEMA Rating | NEMA 4X/IP66 |
| Series | PB1S |
| Width | 3.25 in |
| Application | For 30.5-mm or 22.5-mm oil-tight pushbuttons, switches and pilot lights |
| Standard & Approvals | UL 508A Listed, Type 4, 4X, 12, File Number E61997, cUL Listed per CSA C22.2 No 94, Type 4, 4X, 12, File Number E61997, RoHS Complaint |
| Cover Type | Hinged With Screw |
| Depth | 2-3/4 in |
| Finish | Brushed |
