nVent HOFFMAN Proline™ PST566 P9 Sloped Front HMI Enclosure System, 23.94 in L x 19.98 in W x 19.61 in D, NEMA 12/IP66
nVent HOFFMAN Proline™ PST566 P9 Sloped Front HMI Enclosure System, 23.94 in L x 19.98 in W x 19.61 in D, NEMA 12/IP66
SKU: HOFPST566
Manufacturer Part Number: PST566
UPC: 783510364694
Documents
Features
- Optional PROLINE™ frame shelf or PROLINE™ grid system is recommended to provide a stationary platform for supporting deep equipment
- 17.31 in L x 21.11 in W front opening
- 17.13 x 21.11 in W rear opening
- 14 ga steel material
- The open bottom is suitable for joining the top to a 700 mm PROLINE™ frame
- The bottom of the 600 x 600 mm sizes can be joined through a cutout base to a pedestal or pendant arm system
- A support bracket accessory allows the 600 x 600 mm sizes to be suspended from an overhanging pendant arm
- RAL 7035 light gray textured polyester powder paint finish
Specification
| Material | Steel |
|---|---|
| Finish | Polyester Powder Coated |
| NEMA Rating | NEMA 12/IP66 |
| Length | 500 mm |
| Depth | 19.61 in |
| Color | Light Gray |
| Standard & Approvals | UL 508A File No. E61997, cUL per CSA C22.2 No. 94, IEC 60529 Certified, RoHS Compliant |
| Width | 600 mm |
| Type | Sloped Front |
| Series | P9 |
