Genesis Cable 32071112 Genesis® Type CMP/CL2P/FT6 Shielded Low Voltage Cable, Pull Box Packaging, 300 VAC, (8) 22 AWG Bare Stranded Copper Conductor, 1000 ft L
Genesis Cable 32071112 Genesis® Type CMP/CL2P/FT6 Shielded Low Voltage Cable, Pull Box Packaging, 300 VAC, (8) 22 AWG Bare Stranded Copper Conductor, 1000 ft L
SKU: WCEGEN3207-11-12
Manufacturer Part Number: 32071112
UPC: 619172022507
Documents
Features
- 50 pF/ft nominal capacitance
- 40 Ohm nominal impedance
- UL 910, NFPA 262, CSA FT6 flame rating
- 0.015 in nominal jacket thickness
- 0.044 in nominal insulation diameter
- 0.007 in nominal thickness
- Black/red/white/green/brown/blue/orange/yellow color
- 3-1/2 in nominal lay length
- 24 AWG 7/32 tinned copper drain wire
- 0.001 in THK aluminum mylar shield
- Speed Box® pull box package
- 16.5 Ohm/M at 20 deg C resistance
Specification
| Insulation Material | Plenum PVC |
|---|---|
| Jacket Color | Natural |
| Jacket Material | Plenum PVC |
| Length | 1000 ft |
| Number of Conductors | 8 |
| Outside Diameter | 0.18 in |
| Resistance | 16.5 Ohm |
| Series | Genesis |
| Temperature Rating | -20 to 60 deg C |
| Type | Type CMP/CL2P/FT6 Shielded |
| Voltage Rating | 300 VAC |
| Application | Burglar Alarm, Intercom, Phone and Speakers |
| Standard & Approvals | UL Standards 13 and 444, NEC Articles 725 |
| Conductor Size | 22 AWG |
| Conductor Type | Stranded Bare Copper |
| End Style | Bare Wire |
| Strands | 7/30/2025 12:00:00 AM |
