IDEAL® WIRE-NUT® 30-076J 76B® Flame-Retardant Wire Connector, Twist-On Shell, Fixed/Square Wire Spring, 18 to 6 AWG Solid/Stranded Copper Wire, Polypropylene

Selected 30-076JIDEAL® WIRE-NUT® 30-076J 76B® Flame-Retardant Wire Connector, Twist-On Shell, Fixed/Square Wire Spring, 18 to 6 AWG Solid/Stranded Copper Wire, Polypropylene
30-076JIDEAL® WIRE-NUT® 30-076J 76B® Flame-Retardant Wire Connector, Twist-On Shell, Fixed/Square Wire Spring, 18 to 6 AWG Solid/Stranded Copper Wire, Polypropylene

Documents

Short Description

Wire-Nut® is perfect to twist-on with fingers for a secure connection that will last. The refined wire range makes it the best choice for fine stranded wire applications. The Wire-Nut® also features a tough, flame-retardant thermoplastic shell that withstands environmental extremes and is reusable for easy circuit changes and addition.

Features

  • Fixed, square-wire spring creates its own threads maintains a secure positive grip that will not relax over time
  • No pre-twisting required-positive grip design provides fast, easy installation
  • Deep skirt helps protect against flash-over
  • Reusable for easy circuit changes and additions
  • For tough environmental conditions
  • 5 color coded models
  • 1000 V maximum in fixtures and signs
  • 1 - 6 conductors, (2) 14 AWG - (2) 10 AWG with (2) 12 AWG wire combinations
  • 150/Jar

Specification

Material
Polypropylene Shell and Steel Spring
Catalog ID
IDE30-076J
Color
Red
Dimensions
9/32 in W x 1-1/16 in H
Finish
Zinc Plated
Series
76B
Specifications
1/2 in Solid, 7/16 in Stranded Wire Strip
Temperature Rating
221 deg F
Voltage Rating
600 VAC
Wire Size
18 to 10 AWG
Standard & Approvals
C22.2 #188 CSA Certified, Federal Specification W-S-610E , RoHS Compliant, UL 94V-2 Flammability Rating, UL 486C Listed
Application
For Insulating or Joining One or More Conductors
Wire Type
Aluminum/Copper
Type
Flame-Retardant
Spring Type
Fixed/Square Wire
Order Interval
150
Minimum Order Qty
150
