IDEC RR2P-UCAC120V RR Series Midget Power Relay, 10 A, 2 Form C DPDT Contact, 120 VAC V Coil
Selected IDCRR2P UCAC120V
IDEC RR2P-UCAC120V RR Series Midget Power Relay, 10 A, 2 Form C DPDT Contact, 120 VAC V Coil
SKU: IDCRR2P-UCAC120V
Manufacturer Part Number: RR2P-UCAC120V
Documents
Short Description
RR series relays provide reliable switching for industrial loads. Using pure silver contacts, they are rated up to 10 A and 240 VAC. Terminals are available in two styles, 8 or 11 pin tubular (octal) or 0.187 in plug-in. Coil voltages range from 6 VDC to 240 VAC. Carrying worldwide approvals including UL, CSA, TUV and CE marking (TUV and CE on tubular pin types only), they are ready to travel anywhere your application needs take them. Available options include manual check buttons, LED indicators, or side flange covers for direct surface mounting. When coupled with IDEC's high quality sockets, they form an unbeatable combination.
Features
- High reliability and long service life
- SPDT through 3PDT, 10 A contacts
- 10000000 cycles operation mechanical life
- Silver contact material
- 30 mOhm maximum contact resistance
- 5 to 85% non-condensation relative humidity
- 25 ms maximum operating/release time
- 200000 operation electrical life
Specification
| Contact Rating | 110/220 V AC/30 V DC |
|---|---|
| Terminal Type | Pin |
| Contact Form | 2 Form C DPDT |
| Coil Voltage | 120 V AC |
| Mounting Type | Panel |
| Amperage Rating | 10 A |
| Number Of Poles | 2 |
| Temperature Rating | -25 to 40 deg C |
| Series | RR Series |
| Type | Midget |
| Dimensions | 35.6 mm H x 28.6 mm W |
