ILSCO® SureCrimp® CT-8 CT Series Short Barrel Compression Sleeve, 8 AWG Copper Conductor, Die Code: I-21, 1-1/8 in L, Copper
ILSCO® SureCrimp® CT-8 CT Series Short Barrel Compression Sleeve, 8 AWG Copper Conductor, Die Code: I-21, 1-1/8 in L, Copper
SKU: ILSCT-8
Manufacturer Part Number: CT-8
UPC: 783669116540
Documents
Features
- Manufactured from high strength seamless copper tubing and electro-tin plated
- Short with chamfered end barrel, center wire stop
- Proper high voltage spacings and insulation techniques are used, may be used for high voltage applications up to 35 kV
- Copper class B concentric/compressed, class C concentric strand configurations
- Listed with Ilsco tools ILC-12, ILC-12H, ILCB-12, ILC-14, ILC-14H, ILC-15, MT-25, 94285, IDT-12, IDT-12H, ILC-10, IDTB-12
- Provides low contact resistance, maximum conductivity and excellent crimping characteristics and versatility
- Provides easy conductor insertion and insures maximum cable insertion
- Color code identifies the proper compression die
- Expanded wire size with ILSCO dieless tools and Burndy Y644M dieless tool
- Reduces inventory requirements
- 8 AWG flex, 8 AWG solid alternate wire size
- 50/Pack
Specification
| Length | 1-1/8 in |
|---|---|
| Material | Copper |
| Series | CT |
| Specifications | 5/8 in L Strip, 0.179 in ID x 0.272 in OD |
| Temperature Rating | 90 deg C |
| Type | Short Barrel |
| Voltage Rating | 600 VAC |
| Application | For Splicer/Reducer, Grounding and Bonding Applications |
| Standard & Approvals | LR-29601 CSA Certified, NEBS Level 3, RoHS Compliant, UL 486A-B, UL E6207 453G Listed |
| Conductor Size | 8 AWG |
| Dimensions | 0.179 in ID x 0.272 in OD |
| Color | Red |
| Conductor Type | Copper |
| Connector Type | Crimp |
| Die Code | I-21 |
| Finish | Electro-Tin Plated |
