ILSCO® ClearChoice® GTA-500-500 Type GTA Dual Rated Lay-In Parallel Tap Connector, Aluminum/Copper Conductor, 350 to 500 kcmil Run/Main, 2 AWG to 500 kcmil Tap, Aluminum

Selected GTA-250-0ILSCO® ClearChoice® GTA-500-500 Type GTA Dual Rated Lay-In Parallel Tap Connector, Aluminum/Copper Conductor, 350 to 500 kcmil Run/Main, 2 AWG to 500 kcmil Tap, Aluminum
GTA-250-0ILSCO® ClearChoice® GTA-500-500 Type GTA Dual Rated Lay-In Parallel Tap Connector, Aluminum/Copper Conductor, 350 to 500 kcmil Run/Main, 2 AWG to 500 kcmil Tap, Aluminum

Documents

Features

  • Compact design
  • Range taking for reduced inventories and flexibility
  • Re-usable
  • Dual rated
  • Provides low contact resistance
  • Ensures reliability for copper or aluminum conductors
  • Saves space and reduces installation time
  • Permits inventories to be kept to a minimum
  • Provides efficient use and flexibility in the field
  • No need to break the feeder cable
  • Eliminates taping
  • Manufactured from high strength 6061-T6 aluminum alloy

Specification

Material
Aluminum
Specifications
3/8 in Hex Main, 3/8 in Hex Tap
Tap Size
500 kcmil - 2 AWG
Temperature Rating
90 deg C
Type
Lay-In Type GTA
Voltage Rating
600 VAC
Application
For Use on Copper or Aluminum Conductors
Standard & Approvals
LR-29601 CSA Certified, RoHS Compliant, UL 453G, UL 486A/B, UL E6207 Listed
Dimensions
2-15/16 in L x 1-1/4 in W x 2 in H
Conductor Type
Aluminum/Copper
Finish
Electro-Tin Plated
