ILSCO® NIMBUS® PBTD-4-500 Type PBTD 2-Sided Entry 4-Port Dual Rated Insulated Multi-Tap Connector, Aluminum/Copper Conductor, Aluminum
ILSCO® NIMBUS® PBTD-4-500 Type PBTD 2-Sided Entry 4-Port Dual Rated Insulated Multi-Tap Connector, Aluminum/Copper Conductor, Aluminum
SKU: ILSPBTD-4-500
Manufacturer Part Number: PBTD-4-500
UPC: 783669078442
Documents
Features
- Broad wire range 14 AWG to 750 kcmil
- High dielectric strength plastisol is chemical resistant
- Black cover is UV rated
- Removable port and screw plugs
- Pre-filled with DE-OX® oxide inhibiting compound
- Per NEC article 310-16 allowable ampacities are as follows 4 to 95 A, 1/0 to 170 A, 3/0 to 225 A, 250 to 290 A, 350 to 350 A, 600 to 475 A and 750 to 535 A
- Ensures reliability
- Flexibility in the field
- Entry port closure
- Prevents oxides from forming
- Patented screw design
- Incoming and outgoing conductors must be staggered
Specification
| Material | Aluminum |
|---|---|
| Specifications | 4 AWG to 600 kcmil Wire, 3/8 in Hex, 475 A |
| Temperature Rating | -45 to 90 deg C |
| Type | Type PBTD 2-Sided Entry 4-Port Dual Rated Insulated |
| Voltage Rating | 600 VAC |
| Standard & Approvals | ARRA Compliant, Buy American Act Compliant, RoHS Compliant, CSA File No. LR-29601, UL 486A/486B, UL 453G, UL File No. E6207, PROP65: Cancer and Reproductive Harm - www.p65warnings.ca.gov |
| Dimensions | 5.28 in L x 2.63 in W x 3.04 in H |
| Conductor Type | Aluminum/Copper |
