ILSCO® NIMBUS® PBTS-2-350 Type PBTS 1-Sided Entry 2-Port Dual Rated Insulated Multi-Tap Connector, Aluminum/Copper Conductor, Aluminum
ILSCO® NIMBUS® PBTS-2-350 Type PBTS 1-Sided Entry 2-Port Dual Rated Insulated Multi-Tap Connector, Aluminum/Copper Conductor, Aluminum
SKU: ILSPBTS-2-350
Manufacturer Part Number: PBTS-2-350
UPC: 783669080025
Features
- 350 A amperage rating
- 2 ports
- Broad wire range 750kcmil - 14 AWG
- Dual rated
- High dielectric strength plastisol insulated
- Ensures reliability
- Removable plugs
- Pre-filled with DE-OX® oxide inhibiting compound
- Flexibility in the field
- Black cover is UV rated
- Entry port closure
- Prevents oxides from forming
- Per NEC Article 310-16 Allowable Ampacities are as follows - 4 - 95 Amps, 1/0 - 170 Amps, 3/0 - 225 Amps, 250 - 290 Amps, 350 - 350 Amps, 600 - 475 Amps, 750 - 535 Amps
- Chemical resistant
Specification
| Material | Aluminum |
|---|---|
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Catalog ID | ILSPBTS-2-350 |
| Conductor Type | Aluminum/Copper |
| Dimensions | 2.51 in L x 2.03 in W x 2.62 in H |
| Temperature Rating | -45 to 90 deg C |
| Type | Type PBTS 1-Sided Entry |
| Voltage Rating | 600 VAC |
| Application | For Copper or Aluminum Conductor |
| Standard & Approvals | LR-29601 CSA Certified, RoHS Compliant, UL 453G, UL 486A/B, UL E6207 Listed |
| Specifications | 6 AWG to 350 kcmil Wire, 5/16 in Hex |
