Intermatic® WP1030MXD Heavy Duty Weatherproof While-In-Use Cover, 6.37 in L x 5-3/4 in W x 3-1/8 in D, Receptacle Cover, Die-Cast Aluminum

Selected Intermatic® WP1030MXD Heavy Duty Weatherproof While-In-Use Cover, 6.37 in L x 5-3/4 in W x 3-1/8 in D, Receptacle Cover, Die-Cast Aluminum
Intermatic® WP1030MXD Heavy Duty Weatherproof While-In-Use Cover, 6.37 in L x 5-3/4 in W x 3-1/8 in D, Receptacle Cover, Die-Cast Aluminum

Short Description

The extra duty die-cast aluminum series while-in-use covers are easy to install and shipped with a gasket, mounting screws, base and cover assembly, and inserts for a variety of applications.

Features

  • 6 inserts provided with all models that allow each model to meet multiple installations (up to 70 configurations)
  • Heavy duty die-cast aluminum construction ensures long lasting durability
  • Reinforced hinge pin - designed to exceed 40lb hinge hang/stress test
  • 12 lb impact test to ensure cover remains in-tact
  • Lockable hasp all models accept up to 0.25 in diameter shank
  • Meets requirements for cold impact testing (-60 deg F)
  • 1/8 in thick gasket with slits for mounting screws
  • Easy to install and shipped with a gasket, mounting screws, base and cover assembly, and inserts for a variety of applications
  • Die-cast aluminum finish
  • Neoprene gasket
  • Heavy Duty construction

Specification

Length
6.37 in
Material
Aluminum
Mounting Type
Surface
Number of Gangs
2
Number of Outlets
2
Shape
Rectangle
Temperature Rating
-51 deg C
Type
Weatherproof
Width
5-3/4 in
Application
Schools, Residential, Industrial, Sports Fields, Commercial, Agricultural and Signage
Standard & Approvals
UL Listed, CSA Certified, CEC Rule 26-702, 2014 NEC Article 406.9(B)(1), NEMA 3R, RoHS Compliant
Color
Gray
Depth
79 mm
Includes
WP217 FlexiGuard Duplex and GFCI Inserts, Knockout
