Wiring Device-Kellems HBL430MI7W Mechanical Interlock Device, 480 VAC, 30 A, 3 Poles, 4 Wires
Wiring Device-Kellems HBL430MI7W Mechanical Interlock Device, 480 VAC, 30 A, 3 Poles, 4 Wires
SKU: HWDHBL430MI7W
Manufacturer Part Number: HBL430MI7W
UPC: 783585405971
Features
- 4 to 12 AWG terminal accommodations
- 3-phase
- Valox top and shaft
- K1 K-factor
- Zinc conduit hub
- Brass enclosure inserts
- Nickel plated brass enclosure hinge pins
- Stainless steel hinge spring, assembly screws
- 3000 VAC minimum dielectric withstand voltage
- -40 to 75 deg C temperature rating
Specification
| Material | Valvox |
|---|---|
| Mounting | Screw |
| Number Of Poles | 3 |
| Number of Wires | 4 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 30 A |
| Catalog ID | HWDHBL430MI7W |
| Color | Blue |
| Dimensions | 8-3/4 in W x 11 in H |
| Enclosure | IP67 |
| Power Rating | 15 hp |
| Voltage Rating | 480 VAC |
| Application | For high ampacity connections |
| Standard & Approvals | UL Listed, CSA Certified |
