Keystone Technologies KT-LED10.5T8-48G-8CSJ-DX2 High-Efficiency Linear Lamp, 10.5 W, G13 LED Lamp, T8 Shape, 1650 Lumens
Keystone Technologies KT-LED10.5T8-48G-8CSJ-DX2 High-Efficiency Linear Lamp, 10.5 W, G13 LED Lamp, T8 Shape, 1650 Lumens
SKU: KEYKTLED10.5T848G8CSJDX2
Manufacturer Part Number: KT-LED10.5T8-48G-8CSJ-DX2
UPC: 843654140827
Documents
Features
- Replacement for conventional fluorescent lamp
- Single- or double-ended line voltage wiring
- Instant startup
- Frosted glass lens eliminates pixelation
- Approximately 60 Percent more energy-efficient than standard F32T8 lamps
- Environmentally friendly, No mercury used
- Integral driver (isolated) eliminates the need for external driver or ballast
- Not compatible with Keystone AC emergency drivers, KT-EMRG-LED-5-500-AC, KT-EMRG-LED-5-500-AC/DF, KT-EMRG-LED-12-1200-AC, or KT-EMRG-LED-12-1200-AC /DF
- Not rated for use in Vapor Tight style fixtures
- Lamp is dimmable when used with an appropriate dimming accessory (purchased separately)
Specification
| Wattage | 10.5 W |
|---|---|
| Lamp Base Type | G13 |
| Voltage Rating | 120 to 277 V |
| Lumens | 1650 Lumens |
| Beam Angle | 240 deg |
| Lamp Finish | Frosted |
| Color Rendering Index (CRI) | >80 |
| Shape | T8 |
| Average Life | 50000 hr |
| Start Type | Instant |
| Lamp Type | LED |
| Color Temperature | 3000/3500/4000/5000/6500 K |
| Designation | KT-LED10.5T8-48G-8CSJ-DX2 |
| Dimensions | 1.10 in Dia x 47.20 in L |
| Ballast Type | Integral Driver |
| Type | High-Efficiency |
