Leviton® 5224-2W Duplex Grounding AC Combination Switch With Receptacles, 15 A, 125 VAC, 1800 W, 1 Poles

Selected Leviton® 5224-2W Duplex Grounding AC Combination Switch With Receptacles, 15 A, 125 VAC, 1800 W, 1 Poles
Leviton® 5224-2W Duplex Grounding AC Combination Switch With Receptacles, 15 A, 125 VAC, 1800 W, 1 Poles

Documents

Short Description

With Leviton®'s extensive assortment of combination devices, you can fill a one-gang space with two switches, a switch and receptacle, even a switch and GFCI. From sensor guide lights to multi-purpose styles and tamper resistant receptacles we accommodate your every need. These devices come in a range of colors and are backed by a limited two-year warranty. Built to Last and designed to save space, These attractively styled devices are at home in any setting.

Features

  • -40 to 65 deg C operating temperature
  • Thermoplastic actuator, steel strap
  • 1/2 hp at 120 VAC 12 A maximum amperage AC power ratings
  • AC quiet switches have silver cadmium oxide contacts and receptacles have double wire contacts for maximum conductivity
  • Terminal screw accept up to 12 AWG copper or copper-clad wire
  • Fits standard wallboxes
  • Break-off tabs on devices with switches permit conversion to separate feeds

Specification

Grade
Commercial
Material
Thermoplastic
Mounting
Surface
Number Of Poles
1
Minimum Order Qty
1
Order Interval
1
Catalog ID
LEV5224-2W
Color
White
Dielectric Strength
1500 VAC
Dimensions
4.2 in H x 1.62 in W x 16 in D
Electrical Rating
12 A at 120 VAC
Terminal Type
Side Wired
Type
Duplex Outlet
Wire Size
14 to 12 AWG
Application
Commercial Applications
Standard & Approvals
ANSI C-73, UL 20 File No. E7458, CSA C222.2 No.111, 152105, LR-3413, NOM 057 Approved, NEMA WD-1, WD-6 Compliant
Amperage Rating
12 A
