Lithonia Lighting® CPHB ALO13 MVOLT SWW9 80CRI DWH CPRB Round High Bay Light, Static LED Lamp, 132 W Fixture, 120 to 277 V, White Housing
Lithonia Lighting® CPHB ALO13 MVOLT SWW9 80CRI DWH CPRB Round High Bay Light, Static LED Lamp, 132 W Fixture, 120 to 277 V, White Housing
SKU: LITCPHBALO13MVOLTSWW980C
Manufacturer Part Number: CPHB ALO13 MVOLT SWW9 80CRI DWH
UPC: 196183428561
Documents
Features
- Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life
- Thermally protected driver standard with 0-10V dimming
Specification
| Type | Round |
|---|---|
| Voltage Rating | 120 to 277 V |
| Standard & Approvals | CSA Certified |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Video | https://www.youtube.com/watch?v=sAtRD5yyeeM&feature=youtu.be |
| Average Life | 54000 hr |
| Ballast Type | 0 to 10 V Dimmable |
| Catalog ID | LITCPHBALO13MVOLTSWW980C |
| Color Rendering Index (CRI) | 80 |
| Color Temperature | 4000, 5000 K |
| Dimensions | 3.16 in H x 12.98 in W x 12.98 in L |
| Fixture Wattage | 132 W |
| Housing Finish | White |
| Housing Material | Aluminum |
| Lamp Type | Static LED |
| Lens Type | Polycarbonate Diffuser |
| Lumens | 18000 Lumens |
| Mounting Type | Hook/Pendant/Surface |
| Application | Common Areas, Education, Government, Manufacturing, Offices & Banks, Retail, Retrofit, Warehouses |
| Series | CPRB |
