Littelfuse® POWR-BLOKS™ LD5986-1 LD Series Non-Indicating Power Distribution Block, 600 VAC, 760 A, 1 Poles, 4 AWG to 500 kcmil, 14 to 2/0 AWG Wire, Thermoplastic

Selected LS5301-3Littelfuse® POWR-GARD® POWR-BLOKS™ LPBC4-3 Power Distribution Block Cover, 3 Poles, For Use With Distribution/Splicer Block, Plastic, Clear
LS5301-3Littelfuse® POWR-GARD® POWR-BLOKS™ LPBC4-3 Power Distribution Block Cover, 3 Poles, For Use With Distribution/Splicer Block, Plastic, Clear

Documents

Short Description

POWR-BLOKS™ power distribution blocks offer a safe, convenient way of splicing cables, providing a fixed junction tap-off point or splitting primary power into secondary circuits. LX2XXX-DIN series offers integral DIN rail mount and an optional hinged safety cover. Optional power distribution block covers provide protection against accidental shorting between poles caused by loose wires, tools or other conductive material. They also protect personnel from accidentally contacting energized connectors.

Features

  • (2) 4 AWG to 500 kcmil line, (8) 14 to 2/0 AWG load wire size

Specification

Material
Thermoplastic
Number Of Poles
1
Minimum Order Qty
1
Order Interval
1
Catalog ID
L-FLD5986-1
Color
Black
Dimensions
5.5 in H x 3.17 in W x 3.12 in D
Voltage Rating
600 VAC
Standard & Approvals
UL File No. E171395 Recognized, CSA File No. LR700111, UL 94-V-0 Flammability Rating, PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer
Type
Non-Indicating
Short Circuit Current Rating
100 kA
Series
LD Series
Secondary Connection/Pole
8
Primary Connections/Pole
2
Amperage Rating
760 A
Fuse Type
Class J/T/RK1/RK5/G/CC
Application
For heating, air conditioning and refrigeration systems, elevator systems, material handling equipment, control panels, motor controls, switchgear and anywhere power needs to be distributed to more than one load applications
Wire Size
4 AWG to 500 kcmil, 14 to 2/0 AWG
