Mersen OT600 OT Series Fast Acting Low Voltage North American Style Power Fuse, 600 A, 250 VAC/VDC, 20/50 kA Interrupt, Class: K5, Cylindrical Body

Selected I D W I M A G E a097411cd6ea874722eed50d7a9e740780fb5b01a0dc90aac72dcdca5b864c87
I D W I M A G E a097411cd6ea874722eed50d7a9e740780fb5b01a0dc90aac72dcdca5b864c87

Documents

Short Description

One-Time OT and OTN general purpose fuses provide low cost protection for feeder and branch-circuits serving lighting, heating, and other non-motor loads. OT and OTN fuses will safely interrupt available short-circuit currents up to 50,000 amperes in all ratings. OT and OTN fuses are not rejection fuses and care should be taken to ensure that replacement fuses do not have lower interrupting ratings than original fuses. OTN(15-60) satisfy the Canadian electrical code requirement for Type P low melting-point, non-time-delay fuses.

Features

  • Easy to read imprint label for quick recognition and replacement
  • Low cost for high protection value
  • 50 kA at 250 VAC, 20 kA at 250 VDC interrupt rating

Specification

Voltage Rating
250 VAC/VDC
Body Size
2-9/16 in Dia x 10-3/8 in L
Material
Paper/Polyester
Mounting Type
Clip
Interrupt Rating
20/50 kA
Body Type
Cylindrical
Rejection/Non-Rejection
Non-Rejection
Class
K5
Amperage Rating
600 A
Type
Fast Acting Low Voltage North American Style
Series
OT Series
Terminal Type
Blade
