Midwest® GE U075CP4010 1-Head Unmetered Power Pedestal, 120/240 VAC, 100 A, 1 Phase, 14 to 8 AWG, 14 to 1/0 AWG Wire, NEMA 3R Enclosure

Selected Midwest® GE U075CP4010 1-Head Unmetered Power Pedestal, 120/240 VAC, 100 A, 1 Phase, 14 to 8 AWG, 14 to 1/0 AWG Wire, NEMA 3R Enclosure
Midwest® GE U075CP4010 1-Head Unmetered Power Pedestal, 120/240 VAC, 100 A, 1 Phase, 14 to 8 AWG, 14 to 1/0 AWG Wire, NEMA 3R Enclosure

Documents

Short Description

Midwest Electric's metallic RV units are manufactured using 16 ga, galvanized zinc coated steel and NEMA 3R construction, which resists corrosion and fading and provides lasting service in outdoor applications. Units are available in surface mount and earth burial or pad mount posts, offering a wide range of receptacle configurations to fit your needs.

Features

  • 14 to 8 AWG solid/14 to 1/0 AWG stranded copper, 12 to 8 AWG solid/12 to 1/0 AWG stranded aluminum CB base line connector

Specification

Material
Steel
Mounting Type
Pad Mount Post
Phase
1
Short Circuit Rating
10
Type
1-Head
Voltage Rating
120/240 VAC
Amperage Rating
100 A
Enclosure Type
NEMA 3R
Feed Type
Underground
Circuit Breaker Type
CB120/CB130/CB250
Standard & Approvals
ARRA, Buy American Act, RoHS Compliant, UL/cUL, cULus Listed
Application
Service Equipment
Wire Size
14 to 8 AWG, 14 to 1/0 AWG
Receptacle Type
BR54U/BR32U/5-20R2 GFCI
