NSI Miniterms PT-16V Pin Terminal, 16 to 14 AWG Conductor, 0.078 in Dia x 0.35 in L Pin, Electro-Tin Plated Copper, Blue
NSI Miniterms PT-16V Pin Terminal, 16 to 14 AWG Conductor, 0.078 in Dia x 0.35 in L Pin, Electro-Tin Plated Copper, Blue
SKU: NSIPT-16V
Manufacturer Part Number: PT-16V
UPC: 662381079862
Documents
Features
- Vinyl insulated
- 1 terminal
- Electro-tin plated copper with brazed seam
- 100 Terminals/Pack
Specification
| Material | Copper |
|---|---|
| Overall Length | 0.93 in |
| Minimum Order Qty | 100 |
| Order Interval | 100 |
| Catalog ID | NSIPT-16V |
| Color | Blue |
| Conductor Size | 16 to 14 AWG |
| Pin Diameter | 0.078 in |
| Pin Length | 0.35 in |
| Series | PT |
| Specifications | 0.175 in Maximum Insulation Dia, 0.081 in ID Barrel |
| Temperature Rating | 75 deg C |
| Type | Insulated |
| Voltage Rating | 300 VAC |
| Application | For Terminal Blocks and Wire Termination |
| Standard & Approvals | cULus Listed |
