Broan® 174 Fan Forced Heater, 1.5 kW, 240 VAC
Broan® 174 Fan Forced Heater, 1.5 kW, 240 VAC
SKU: BRO174
Manufacturer Part Number: 174
UPC: 026715002573
Documents
Short Description
Features
- Factory wired for 1500 W at 120 VAC easily converts to 750 W at 120 VAC or 1500 W at 240 VAC
- Clean, white, baked enamel grille finish, front-mounted, built-in adjustable thermostat automatically maintains desired temperature and features a color-coordinated knob
- Heavy 20 gauge steel louvered to direct air downward for even room heating
- Housing 24 gauge steel finished with black epoxy paint, grille material 20 gauge steel
- 100% efficient heating element alloy heating element provides comfortable heat in seconds
- Complete assembly removes from housing for easy cleaning
- Permanently lubricated motor
- Zig-zag element configuration insulated with mica
- Manual-reset thermal overload protection
- Grille - designer-styled, one-piece construction with rounded corners
- Removable wiring cover - connect wiring away from tight corners
- Snap-action, bi-metallic thermostat, High-efficiency blower wheel
- 120/208/240 VAC voltage rating, 12.5/6.2, 5.41, 6.25 A ampere rating, 2000/1000 W at 240 VAC, 1500/750 W at 208 VAC power rating
- 5120/2560 Btu/hr at 120 VAC, 3840 Btu/hr at 208 VAC, 5120 Btu/hr at 240 V
- Single pack
- 9-1/4 in H x 1/2 in W x 12 in D Grille
- 7-3/4 in H x 3-3/4 in W x 10-1/4 in D Housing
- Steel grille
Specification
| Material | Steel |
|---|---|
| Mounting Type | Wall |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 6.25 A |
| Capacity | 5120 Btu |
| Catalog ID | BRO174 |
| Color | White |
| Finish | Black Expoxy Paint Housing |
| Type | Fan-Forced |
| Voltage Rating | 240 VAC |
| Standard & Approvals | UL Listed |
| Includes | Housing Mask to Prevent Construction Damage to Roughed in Heater, Heater Assembly Nickel-Chrome Resistance Alloy Heating Element |
| Application | For Bathrooms or Other Areas That Requires Added Warmth on Demand |
| Power Rating | 1500 W |
