NUVO® by SATCO 65-770R3 High Bay Fixture, 80, 100, 120 W Fixture, 120 to 347 V, Black Housing

Selected NUVO by SATCO 65 770R3 4
NUVO by SATCO 65 770R3 4

Short Description

SATCO NUVO's Round High Bay Field Selectable fixtures offer an energy efficient and low-maintenance alternative to traditional HID fixtures. These luminaires are field selectable, giving users the flexibility to choose from three wattage and three CCT options during installation. The fixtures are constructed with a durable die-cast aluminum housing and an IK08 impact-rated polycarbonate lens. Featuring 6kV surge protection, 120V-347V range voltage and NEMA 4X (IP65) wet location rating, these high bays are resilient in various commercial environments. Compatible with a wide variety of accessories (sold separately) fixtures can be customized to accommodate a multitude of lighting needs.|SATCO NUVO's 65-770R3 Round High Bay Field Selectable fixture in a black finish, offers an energy efficient and low-maintenance alternative to traditional HID fixtures. This luminary is field selectable, giving users the flexibility to choose from three wattage and three CCT options during installation. The fixture is constructed with a durable die-cast aluminum housing and an IK08 impact-rated polycarbonate lens. Featuring 6kV surge protection, 120V-347V range voltage and NEMA 4X (IP65) wet location ratings, this high bay is resilient in various commercial environments. Compatible with a wide variety of accessories (sold separately) this fixture can be customized to accommodate a multitude of lighting needs.

Features

  • CCT and Wattage Selectable
  • Integrated Sensor Port
  • EM Battery Backup Capable
  • 6 Foot Supply and Low Voltage Whips
  • 6kV Surge Protection

Specification

Voltage Rating
120 to 347 V
Lamp Wattage
80, 100, 120 W
Housing Finish
Black
Enclosure Type
IP65
Lens Type
Polycarbonate
Lamp Base Type
Integrated
Ballast Type
0 to 10 V Dimmable
Color Rendering Index (CRI)
80
Color Temperature
3000, 4000, 5000 K
Housing Material
Die-Cast Aluminum
Dimensions
7.3 in H x 11 in W
Lumens
11840 to 18600 Lumens
Fixture Wattage
80, 100, 120 W
