NUVO® by SATCO 65-771R3 High Bay Fixture, 150, 175, 200 W Fixture, 120 to 347 V, Black Housing

Selected NUVO by SATCO 65 771R3 3
NUVO by SATCO 65 771R3 3

Short Description

SATCO NUVO's Round High Bay Field Selectable fixtures offer an energy efficient and low-maintenance alternative to traditional HID fixtures. These luminaires are field selectable, giving users the flexibility to choose from three wattage and three CCT options during installation. The fixtures are constructed with a durable die-cast aluminum housing and an IK08 impact-rated polycarbonate lens. Featuring 6kV surge protection, 120V-347V range voltage and NEMA 4X (IP65) wet location rating, these high bays are resilient in various commercial environments. Compatible with a wide variety of accessories (sold separately) fixtures can be customized to accommodate a multitude of lighting needs.|SATCO NUVO's 65-771R3 Round High Bay Field Selectable fixture in a black finish, offers an energy efficient and low-maintenance alternative to traditional HID fixtures. This luminary is field selectable, giving users the flexibility to choose from three wattage and three CCT options during installation. The fixture is constructed with a durable die-cast aluminum housing and an IK08 impact-rated polycarbonate lens. Featuring 6kV surge protection, 120V-347V range voltage and NEMA 4X (IP65) wet location ratings, this high bay is resilient in various commercial environments. Compatible with a wide variety of accessories (sold separately) this fixture can be customized to accommodate a multitude of lighting needs.

Features

  • CCT and Wattage Selectable
  • Integrated Sensor Port
  • EM Battery Backup Capable
  • 6 Foot Supply and Low Voltage Whips
  • 6kV Surge Protection

Specification

Dimensions
7.3 in H x 13.4 in W
Color Temperature
3000, 4000, 5000 K
Enclosure Type
IP65
Fixture Wattage
150, 175, 200 W
Color Rendering Index (CRI)
80
Voltage Rating
120 to 347 V
Ballast Type
0 to 10 V Dimmable
Housing Finish
Black
Lamp Base Type
Integrated
Housing Material
Die-Cast Aluminum
Lamp Wattage
150, 175, 200 W
Lumens
22200 to 28800 Lumens
Lens Type
Polycarbonate
