O-Z/Gedney TB-75 Type TB Conduit Outlet Body, 3/4 in Hub, 7 cu-in, Malleable Iron, Zinc Electroplated/Aluminum Enamel
O-Z/Gedney TB-75 Type TB Conduit Outlet Body, 3/4 in Hub, 7 cu-in, Malleable Iron, Zinc Electroplated/Aluminum Enamel
SKU: OZGTB-75
Manufacturer Part Number: TB-75
UPC: 783126522464
Short Description
Features
- Tapered threaded hubs (NPT)
- Raintight when used with gasketed covers
- Malleable iron suitable for use in concrete
- Complete interchangeability with other manufacturers style 5 or 35 conduit bodies
- Internal volume and maximum wire capacity clearly marked on castings
- Suitable for wet locations when used with gasketed covers
- Serve as pulling fittings
- Provide openings for splicing
- Connect and change direction of conduit runs
- Allow connections for branch runs
- Permit access to conductors for maintenance
- 3 (NO 6 AWG) Conductors
- Allows connection of straight conduit runs, branch conduit runs and 90 deg bends.
- Tapered FNPT Connection
- Zinc Electroplated With Aluminum Enamel
Specification
| Hub Size | 3/4 in |
|---|---|
| Material | Malleable Iron |
| Number of Hubs | 3 |
| Type | Type TB |
| Application | For rigid and IMC conduit and used to make bends in conduit system, to provide access to conductors for pulling, splicing, maintenance and future changes/upgrades |
| Standard & Approvals | UL E18095 Listed, CSA LR-9795 Certified, Applicable Third Party Standards: UL 514A, CSA C22.2 NO 18, Federal Specification Number A-A-50563, Hazardous Locations Class 1, Division 2 Per NEC Section 501-4(B) |
| Dimensions | 6-1/4 in L x 1-1/2 in W |
| Connection Type | FNPT |
| Enclosure | NEMA FB-1/FB-2.10 |
| Finish | Zinc Plated |
| Capacity | 7 cu-in |
