O-Z/Gedney TB37 Type TB Conduit Outlet Body, 1 in Hub, Form 7 Form, 15 cu-in Capacity, Grayloy Iron, Zinc Electroplated/Aluminum Enamel

Selected O-Z/Gedney TB37 Type TB Conduit Outlet Body, 1 in Hub, Form 7 Form, 15 cu-in Capacity, Grayloy Iron, Zinc Electroplated/Aluminum Enamel
O-Z/Gedney TB37 Type TB Conduit Outlet Body, 1 in Hub, Form 7 Form, 15 cu-in Capacity, Grayloy Iron, Zinc Electroplated/Aluminum Enamel

Documents

Short Description

Every O-Z/Gedney electrical product is built to pass a simple test. Time. O-Z/Gedney has over 150 years of experience in outfitting electrical infrastructure in commercial and industrial applications, with solutions that ensure reliable and durable installations to help process our food, clean our water, generate our power and get us safely from place to place. Our materials, field research and design innovation come together in products that are unsurpassed for quality.

Features

  • Tapered threaded hubs (NPT)
  • Flat back design for greater wiring capacity and surface mounting
  • Complete interchangeability with other manufacturers Form 7 conduit bodies
  • Internal volume and maximum wire capacity clearly marked on castings
  • Suitable for wet locations when used with gasketed covers
  • Time-saving Clip-On™ cover
  • Serve as pulling fittings
  • Provide openings for splicing
  • Connect and change direction of conduit runs
  • Allow connections for branch runs
  • Permit access to conductors for maintenance
  • 3 (NO 4 AWG) Conductors
  • Allows connection of straight conduit runs, branch conduit runs and 90 deg bends.
  • Tapered FNPT Connection
  • Zinc Electroplated With Aluminum Enamel

Specification

Hub Size
1 in
Material
Iron
Number of Hubs
3
Minimum Order Qty
1
Order Interval
1
Catalog ID
OZGTB37
Color
Gray
Connection Type
FNPT
Dimensions
7-1/4 in L x 2 in W x 3-1/4 in H
Enclosure
NEMA FB-1/FB-2.10
Finish
Zinc Plated
Form
7
Type
Type TB
Application
For rigid and IMC conduit and used to make bends in conduit system, to provide access to conductors for pulling, splicing, maintenance and future changes/upgrades
Standard & Approvals
UL E18095 Listed, CSA LR-9795 Certified, Applicable Third Party Standards: UL 514A, CSA C22.2 NO 18, Federal Specification Number A-A-50563, Hazardous Locations Class 1, Division 2 Per NEC Section 501-4(B)
Capacity
15 cu-in
