Pass & Seymour® 695WG 3-Way Grounding Combination Switch/Receptacle, 120/125 VAC, 15 A
Pass & Seymour® 695WG 3-Way Grounding Combination Switch/Receptacle, 120/125 VAC, 15 A
SKU: P-S695-WG
Manufacturer Part Number: 695WG
UPC: 785007006193
Documents
Features
- Easily accessible break-off separate or common feed
- Long-life red neon lamp in pilot light rated 1/25 W, 125 V
- Two devices fit into the space of one
- Grounding combination devices meet NEC requirements
- Tamper-resistant version features dual mechanical shutter system to help prevent insertion of foreign objects
- Side wire 12 and 14 AWG
Specification
| Lamp Type | Neon |
|---|---|
| Lamp Wattage | 0.04 W |
| Material | Thermoplastic |
| Mounting | Wall |
| Number Of Poles | 3 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 15 A |
| Catalog ID | P-S695-WG |
| Color | White |
| Contact Configuration | 1NO |
| Contact Rating | 15 A 120/125 VAC |
| Dimensions | 1.32 in L x 0.94 in W x 4.06 in H |
| Enclosure | NEMA 5-15R |
| Temperature Rating | -30 to 60 deg C |
| Type | 3-Way |
| Voltage Rating | 120/125 VAC |
| Application | For residential and commercial applications |
| Standard & Approvals | UL 20, cUL Listed |
