Pass & Seymour® PS5269-X Wire Grounding Straight Blade Plug, 125 VAC, 15 A, 2 Poles, 3 Wires, Black/White
Pass & Seymour® PS5269-X Wire Grounding Straight Blade Plug, 125 VAC, 15 A, 2 Poles, 3 Wires, Black/White
SKU: P-SPS5269-X
Manufacturer Part Number: PS5269-X
UPC: 785007237306
Documents
Features
- Unit arrives completely ready-to-wire, cuts installation time significantly
- Nylon housing provides impact and chemical resistance
- Rugged two-piece cord grip provides more uniform cord retention
- Internal dust shield keeps terminals free of contaminants
- Tri-drive assembly screws are standard on all Specification Grade plugs and connectors
- All 3-wire terminals located on the same plane, allows for quick wire termination from any angle
- Heavy-duty brass alloy blades and contacts, resist heat rise, provide excellent conductivity
- Cord-grip screws recessed to protect installer against screwdriver head slippage
- 0.23 - 0.72 in Cord
Specification
| Grade | Commercial |
|---|---|
| Material | Nylon |
| NEMA Rating | NEMA 5-15R |
| Number Of Poles | 2 |
| Number of Wires | 3 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 15 A |
| Color | Black/White |
| Temperature Rating | -40 to 75 deg C |
| Voltage Rating | 125 VAC |
| Standard & Approvals | cULus Listed, RoHS Compliant |
| Dimensions | 1.516 in H x 1.516 in W x 2.638 in D |
| Catalog ID | P-SPS5269-X |
