DeWALT® 1151 Short Lag Shield, 3/8 in Dia, 1-3/4 in OAL, 5/8 in Drill, Zamak Alloy

Selected 1151DeWALT® 1151 Short Lag Shield, 3/8 in Dia, 1-3/4 in OAL, 5/8 in Drill, Zamak Alloy
1151DeWALT® 1151 Short Lag Shield, 3/8 in Dia, 1-3/4 in OAL, 5/8 in Drill, Zamak Alloy

Documents

Short Description

The lag Shield™ is a screw style anchor designed for use with lag bolts. It is suitable for use in concrete and the mortar joints of block or brick walls. Lag Shield™ anchors are formed from Zamac alloy. In harder masonry materials, short style lag shields are used to reduce drilling time. The long style version is used in soft or weak masonry to better develop strength.

Features

  • Ideal for use in masonry materials
  • Internally threaded anchor for easy removability and service work

Specification

Material
Zamac Alloy
Minimum Order Qty
50
Order Interval
50
Catalog ID
RAW01151
Diameter
3/8 in
Drill Size
5/8 in
Standard & Approvals
ASTM E488
Overall Length
1-3/4 in
Minimum Embedment Depth
1-3/4 in
Application
Hard and Soft Base Materials, Mortar Joints, Shallow Attachments and Masonry Anchorage
Type
Short
Thread Length
1 in
