Red Dot® ALR-10 Type LR Conduit Body, 4 in Hub, 366 cu-in Capacity, Die Cast Aluminum, Powder Coated Urethane

Selected Red Dot® ALR-10 Type LR Conduit Body, 4 in Hub, 366 cu-in Capacity, Die Cast Aluminum, Powder Coated Urethane
Red Dot® ALR-10 Type LR Conduit Body, 4 in Hub, 366 cu-in Capacity, Die Cast Aluminum, Powder Coated Urethane

Documents

Short Description

Preferred for more than 50 years, Red Dot® weatherproof and conduit body solutions withstand the harshest elements and ensure trouble-free installation and years of superior performance.

Features

  • Retained stainless steel cover screws
  • Right side access opening
  • Smooth throats for easy wire pulling
  • Spacious, accessible wiring chamber provides a convenient location to pull conductors and make splices
  • Threaded conduit bodies maintain a weather resistant conduit system when used with covers and gaskets
  • 500 MCM max wire fill
  • Copper Free Die Cast Aluminum

Specification

Hub Size
4 in
Material
Aluminum
Number of Hubs
2
Minimum Order Qty
1
Order Interval
1
Connection Type
Threaded
Series
A
Type
Type LR
Standard & Approvals
CSA Certified, UL Listed, RoHS Compliant
Application
For pulling, splicing and maintenance
Finish
Powder Coated Urethane
Dimensions
16-1/4 in L x 6-1/2 in W x 5-1/2 in H
Catalog ID
R-DALR-10
Capacity
366 cu-in
