Red Dot® ALR-6 Type LR Conduit Body, 2 in Hub, 69.5 cu-in Capacity, Die Cast Aluminum, Powder Coated Urethane

Selected Red Dot® ALR-6 Type LR Conduit Body, 2 in Hub, 69.5 cu-in Capacity, Die Cast Aluminum, Powder Coated Urethane
Red Dot® ALR-6 Type LR Conduit Body, 2 in Hub, 69.5 cu-in Capacity, Die Cast Aluminum, Powder Coated Urethane

Documents

Short Description

Preferred for more than 50 years, Red Dot® weatherproof and conduit body solutions withstand the harshest elements and ensure trouble-free installation and years of superior performance.

Features

  • Retained stainless steel cover screws
  • Right side access opening
  • Smooth throats for easy wire pulling
  • Spacious, accessible wiring chamber provides a convenient location to pull conductors and make splices
  • Threaded conduit bodies maintain a weather resistant conduit system when used with covers and gaskets
  • 4/0 AWG max wire fill
  • Copper Free Die Cast Aluminum

Specification

Hub Size
2 in
Material
Aluminum
Number of Hubs
2
Minimum Order Qty
1
Order Interval
1
Capacity
69.5 cu-in
Catalog ID
R-DALR-6
Connection Type
Threaded
Dimensions
10-3/16 in L x 3-15/16 in W x 3-7/16 in H
Finish
Powder Coated Urethane
Series
A
Type
Type LR
Application
For pulling, splicing and maintenance
Standard & Approvals
CSA Certified, UL Listed, RoHS Compliant
