Rittal 3108115 SK Series Enclosure Internal Fan, 115 VAC, 0.23/0.24 A, 19/18 W Power Rating, 100 cfm Air Flow
Rittal 3108115 SK Series Enclosure Internal Fan, 115 VAC, 0.23/0.24 A, 19/18 W Power Rating, 100 cfm Air Flow
SKU: RTL3108115
Manufacturer Part Number: 3108115
UPC: 639889200616
Documents
Features
- Complete unit ready for connection with radial fan and lockable swivel bracket and assembly parts
- For TS8 modular server enclosures
- Used to prevent hot spots and support the air routing of active enclosure climate control components
- Adjustable in two axes
- Attached to the TS8 frame section
- Several fans may be cascaded using the quick-release clamping strip
Specification
| Power Rating | 19/18 W |
|---|---|
| Series | SK Series |
| Voltage Rating | 115 VAC |
| Application | Climate Control Solutions |
| Standard & Approvals | RoHS Compliant |
| Amperage Rating | 0.23/0.24 A |
| Dimensions | 120 mm W x 213.5 mm H |
| Air Flow Rate | 100 cfm |
| Includes | Complete Unit With Radial Fan Ready for Connection, Snap-On Pivot Device and Fasteners |
