Rittal 8017664 Miniature Pushbutton Enclosure, 3.2 in L x 2.7 in W x 3-1/2 in D, NEMA 12/13, Carbon Steel
Rittal 8017664 Miniature Pushbutton Enclosure, 3.2 in L x 2.7 in W x 3-1/2 in D, NEMA 12/13, Carbon Steel
SKU: RTLPB01225M1C
Manufacturer Part Number: 8017664
UPC: 639889811546
Documents
Features
- Captive, plated cover screws
- External mounting brackets
- Cover screws, captive, Wall mounting brackets, description
- 22.5 mm hole size
- 1 hole
- Polyester-urethane powder coat over phosphatized surface
- Sheet steel door material, all-round foamed-in PU seal, enclosure, dipcoat primed enclosure and cover
- The NEMA rated PB series pushbutton box enclosure
- This enclosure protects equipment from dirt, dust, sprayed water, oil, and coolants
- Enclosures and covers are made from 14 gauge carbon steel for strength and durability
Specification
| Length | 3.2 in |
|---|---|
| Material | Carbon Steel |
| Mounting Type | Wall |
| NEMA Rating | NEMA 12/13 |
| Type | Miniature |
| Width | 2.7 in |
| Application | For indoor use to house pushbuttons, selector switches, and pilot lights |
| Standard & Approvals | UL File No. E118617, UL Listed, cUL Certified, RoHS Complaint |
| Color | Light Gray |
| Cover Type | Screw |
| Depth | 3-1/2 in |
| Finish | Powder Coated |
