Scotch® 054007-04833 Premium Grade Electrical Tape, 36 yd L x 1 in W x 8 mil THK, Cambric Fabric, Yellow
Scotch® 054007-04833 Premium Grade Electrical Tape, 36 yd L x 1 in W x 8 mil THK, Cambric Fabric, Yellow
SKU: 3-M2520-1X36YD
Manufacturer Part Number: 054007-04833
UPC: 054007048336
Documents
Short Description
Features
- Excellent dielectric strength
- High puncture and cut-through resistance
- Varnish cambric tapes are rated for Class A
- Non-corrosive adhesive on 2520 tape. Adhesive holds film in position until the jacket is applied
- Electrical properties are stable up to 105 deg C
- Straight-cut woven cotton cambric fabric, oil primed and coated with a high-grade yellow electrical insulating varnish
- Flexible, electrically insulating and moisture resistant with a smooth finish
- Excellent dielectric strength with high puncture and cut-through resistance
- Pressure-sensitive adhesive holds tape in position after application
- Straight Cut Woven Cotton Cambric Fabric With Electrical Insulating Varnish
- Woven Cotton Cambric Fabric
- 13 in-oz Adhesion to Steel, 8 in-oz Adhesion to Backing adhesion
Specification
| Length | 36 yd |
|---|---|
| Material | Cambric Fabric |
| Shape | Roll |
| Temperature Rating | 105 deg C |
| Thickness | 8 mil |
| Type | Premium Grade |
| Width | 1 in |
| Adhesion Strength | 13 in-oz |
| Adhesive Material | Rubber |
| Backing Material | Cotton Cloth |
| Color | Yellow |
| Dielectric Strength | 800 V/mil |
| Standard & Approvals | ASTM D-1000,¿ ASTM D-374,¿ ASTM D-295, RoHS Compliant |
| Application | For insulating bus bars, motor leads (for re-entry), and service drop connections |
| Tensile Strength | 6250 psi |
