Scotch® 054007-10356 Premium Grade Electrical Tape, 36 yd L x 2 in W x 8.5 mil THK, PVC, Black
Scotch® 054007-10356 Premium Grade Electrical Tape, 36 yd L x 2 in W x 8.5 mil THK, PVC, Black
SKU: 3-M88-SUPER-2X36YD
Manufacturer Part Number: 054007-10356
UPC: 054007103561
Documents
Short Description
Features
- Excellent resistance to UV rays, abrasion, moisture, alkalies, acids, corrosion and varying weather conditions
- Provides primary electrical insulation for splices up to 600V
- Compatible with solid dielectric cable insulations
- Compatible with rubber and synthetic splicing compounds, as well as epoxy and polyurethane resins
- Inhibits corrosion of electrical conductors
- 60 in-oz at -18 deg C, 28 in-oz at 22 deg C adhesion
Specification
| Length | 36 yd |
|---|---|
| Material | PVC |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Adhesion Strength | 60 in-oz |
| Adhesive Material | Rubber |
| Backing Material | PVC |
| Catalog ID | 3-M88-SUPER-2X36YD |
| Color | Black |
| Dielectric Strength | 1150 V/mil |
| Shape | Roll |
| Temperature Rating | -18 to 150 deg C |
| Tensile Strength | 20 in-lb |
| Thickness | 8.5 mil |
| Type | Premium Grade |
| Voltage Rating | 600 VAC |
| Width | 2 in |
| Application | For primary electrical insulation for 600-volt bus applications, protective jacketing for high- and low-voltage bus, high-voltage cable splices and repairs, harnessing of wires and cables |
| Standard & Approvals | UL 510 File No. E129200, CSA C22.2 File No. LR 48769, RoHS 2002/95/EC Compliant |
