Siemens 45EG20AG Class 45 Non-Reversing Definite Purpose Contactor, 240 V Coil, 30 A, 2 Poles
Siemens 45EG20AG Class 45 Non-Reversing Definite Purpose Contactor, 240 V Coil, 30 A, 2 Poles
SKU: SIE45EG20AG
Manufacturer Part Number: 45EG20AG
UPC: 783087147607
Documents
Specification
| Frequency Rating | 50/60 Hz |
|---|---|
| Maximum Load Current | 30 A |
| Mounting Type | Surface |
| Number Of Poles | 2 |
| Operating Cycles | 250000 cycles |
| Operating Temperature | 158 deg F |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Catalog ID | SIE45EG20AG |
| Coil Voltage | 240 V |
| Dimensions | 3.19 in H x 1.97 in W x 2.46 in D |
| Terminal Type | Screw |
| Type | Class 45 Non-Reversing |
| Standard & Approvals | ARI 780/790, cULus Recognized, ECCN:EAR99, UL File No. E14900, REACH Article 33 |
