SIMATIC 6ES71324BF000AA0 PLC Digital Electronic Output Module, 4 Outputs, -1 VAC
SIMATIC 6ES71324BF000AA0 PLC Digital Electronic Output Module, 4 Outputs, -1 VAC
SKU: SIE6ES71324BF000AA0
Manufacturer Part Number: 6ES71324BF000AA0
EAN: 4025515074670
UPC: 662643216585
Features
- 500 VDC isolation
- Can be plugged onto TM-E terminal modules with automatic coding
- Hot swapping of modules possible
- 48 to 3400 Ohm load resistance
- 1000 m L (shielded) and 600 m L (unshielded) cable
Specification
| Number of Outputs | 4 |
|---|---|
| Power Rating | 1.5 W |
| Signal Range | -1 VAC |
| Temperature Rating | -25 to 70 deg C |
| Voltage Rating | 24 VDC |
| Amperage Rating | 0.5 A |
| Application | For ET 200S distributed I/O system |
| EANUCC13 | 4025515074670 |
| Dimensions | 52 mm L x 15 mm W x 81 mm H |
