SIMATIC 6ES75325HF000AB0 Analog Output Module, 8 Outputs, 16 bit Resolution, 0.3% Accuracy
SIMATIC 6ES75325HF000AB0 Analog Output Module, 8 Outputs, 16 bit Resolution, 0.3% Accuracy
SKU: SIE6ES75325HF000AB0
Manufacturer Part Number: 6ES75325HF000AB0
EAN: 4025515080176
UPC: 887621139179
Documents
Specification
| Number of Outputs | 8 |
|---|---|
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 260 mA |
| Catalog ID | SIE6ES75325HF000AB0 |
| Conversion Rate | 50 us |
| Dimensions | 147 mm H x 35 mm W x 129 mm D |
| Resolution | 16 bit |
| Voltage Rating | 24 VDC |
| Application | For S7-1500 software controller |
| Accuracy | 0.003 |
| EANUCC13 | 4025515080176 |
