Siemens 6SE64402UD175AA1 Micromaster 440 Inverter Drive, 380 to 480 VAC, 2.2 A, 1 hp, 173 mm H x 73 mm W
Siemens 6SE64402UD175AA1 Micromaster 440 Inverter Drive, 380 to 480 VAC, 2.2 A, 1 hp, 173 mm H x 73 mm W
SKU: SIE6SE64402UD175AA1
Manufacturer Part Number: 6SE64402UD175AA1
EAN: 4019169450331
UPC: 783087635685
Documents
Features
- -10 to 50 deg C ambient
- 0.75 kW squared/constant torque power
- 150% output current for 60 sec, followed by 100% output current for 240 sec in a 300 sec cycle time high overload
- 3-phase AC input, 3-phase AC output
- 380 to 480 VAC 10/-10 % line voltage
- 3.7 A rated input current, 2.2 A rated output current
- 47 to 63 Hz line frequency, 4000 Hz pulse frequency
- Fan cooling
- 2.5 sq-mm motor end conductor cross-section
- 6 standard digital inputs, 2 analog input
- 3 relay output, 2 analog output and 1 PTC/ KTY interface
- 0.95 power factor
- 0.96 efficiency
- Without filter
- FSA frame size
- Wall mount in clean environment or cubicle mount
- Without AOP/BOP
Specification
| Height | 173 mm |
|---|---|
| Mounting Type | Wall |
| Series | Micromaster 440 |
| Voltage Rating | 380 to 480 VAC |
| Width | 73 mm |
| Amperage Rating | 2.2 A |
| Depth | 149 mm |
| EANUCC13 | 4019169450331 |
| Enclosure Type | IP20 |
| Horsepower | 1 hp |
