Siemens LGB3B090B Low Voltage Molded Case Circuit Breaker, 480 VAC, 90 A, 65 kA, 3 Poles, Thermal Magnetic Trip
Siemens LGB3B090B Low Voltage Molded Case Circuit Breaker, 480 VAC, 90 A, 65 kA, 3 Poles, Thermal Magnetic Trip
SKU: SIELGB3B090B
Manufacturer Part Number: LGB3B090B
UPC: 887621220327
Features
- The GB circuit breaker includes the same design features as the GG except the line end of the breaker is configured for panel board mounting applications and it is without some of the global markings
- 8 to 1/0 AWG copper, 8 to 2/0 AWG aluminum
Specification
| Frame | LGB/125A |
|---|---|
| Frequency Rating | 50/60 |
| Interrupt Rating | 65 |
| Mounting Type | Panel |
| Number Of Poles | 3 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 90 A |
| Catalog ID | SIELGB3B090B |
| Connection Type | Load Lug/Low Tab |
| Dimensions | 2.87 in L x 2.96 in W x 4.99 in H |
| Phase | 3 |
| Temperature Rating | 40 |
| Trip Type | Thermal Magnetic |
| Type | Low Voltage |
| Voltage Rating | 480 V |
| Wire Size | 8 to 1/0 AWG, 8 to 2/0 AWG |
| Application | Industrial Applications |
| Standard & Approvals | ARRA, Buy American Act and RoHS Compliant, UL 489, CSA C22.2 |
