Siemens SPEEDFAX™ SNW0816B1200T Standard SN Series 1-Phase Assembled Low Voltage Main Breaker Load Center With Aluminum Bus Bar, Gray Trim and Feed-Thru Lugs, 120/240 VAC, 200 A, 22 kAIC Interrupt

Selected SN4040B1200WSiemens SPEEDFAX™ SN2424L1125 Standard SN Series 1-Phase Assembled Low Voltage Main Lug Load Center With Aluminum Bus Bar and Gray Combination Trim, 120/240 VAC, 125 A, 100 kAIC Interrupt
SN4040B1200WSiemens SPEEDFAX™ SN2424L1125 Standard SN Series 1-Phase Assembled Low Voltage Main Lug Load Center With Aluminum Bus Bar and Gray Combination Trim, 120/240 VAC, 125 A, 100 kAIC Interrupt

Documents

Short Description

SN series load center is the smart choice when value and quick installation are of the highest priority. The SN series load centers include labor saving features such as the ability to accept plug-on neutral breakers, patented Insta wire and mounting trim tabs. These exclusive features make the SN series load center the best load center for the value minded contractor.

Features

  • Quicker breaker installation
  • Wiring made easier with the neutral lug removed on CAFCI breakers
  • Small electronic breaker footprint
  • Design allows for neutral terminal accessibility
  • Over 4 in of wire bending space
  • Neutral clip is the same as line side
  • Durable hook rail
  • Main breaker is factory installed
  • Designed for use with plug-on neutral breaker

Specification

Interrupt Rating
22 kAIC
Number of Circuits
16
Number of Spaces
8
Series
Standard SN Series
Type
1-Phase Assembled Low Voltage
Voltage Rating
120/240 VAC
Wiring Configuration
3-Wire
Application
Outdoor Applications
Standard & Approvals
NEC, NEMA 250, UL E10703
Amperage Rating
200 A
Enclosure Box Size
14-1/2 in W x 4-1/2 in D x 23 in H
Enclosure Type
NEMA 3R
